1.5Ton Wheel Excavator

Flexible steering!

versatility!

Good off-road performance!



Product Details

Advantages and Characteristics

Strong Mobility

Wheeled excavators are equipped with tire-based traveling devices, enabling them to achieve relatively high driving speeds. Generally, the traveling speed of domestically produced wheeled excavators ranges from 20 to 35 km/h, and some models can even reach up to 54 km/h. They are capable of self-transportation over long distances and can rapidly reach different construction sites. This feature significantly reduces transportation costs and saves time.

Flexible Operation

These excavators have the ability to swiftly switch between various operating attachments. For instance, they can use buckets, hydraulic breakers, soil rippers, electromagnetic suction cups, quick-change devices, etc. This versatility allows them to perform multiple functions including digging, filling, crushing, and leveling, making them adaptable to diverse construction requirements.

Comfortable Operation Environment

They are outfitted with a new generation of cabs and seats, along with updated interior decor. The inclusion of a new automatic air conditioning system that features an automatic air distribution function creates a comfortable working environment for operators. Additionally, a large color display screen enables real-time monitoring of the machine's operating status. It also comes with a fault self-diagnosis and recording function, an electric throttle, and multiple working modes for selection.

Easy Maintenance

Certain models adopt a large-area open cover design, allowing maintenance work to be carried out while standing on the ground. Components such as the air filter, primary fuel filter, secondary fuel filter, oil filter, and pilot filter are all easily accessible. Moreover, the grease filling ports on the working device are centrally located, facilitating convenient maintenance procedures.

Wide Application Scope

Wheeled excavators are extensively utilized in various operating scenarios, including airports, ports, oil fields, mines, urban and rural construction, as well as farmland water conservancy projects. They are particularly well-suited for urban pipeline laying, material handling operations, small-scale municipal engineering projects, and water conservancy projects.

Engine model

4BTAA3.9-C125

Engine power

93kw/2200rpm

Weight of the whole machine

14000kg

Bucket capacity

0.60m³

Total length of transportation time

7350mm

Sleeve length

4500mm

The total height of transportation:

3150mm

Length of the bucket rod:

2500mm

Width of the whole machine:

2550mm

Height of bulldozer:

560mm

Width of the turn table:

2430mm

Width of bulldozer:

2600mm

Wheelbase:

2650mm

Lifting height of bulldozer:

420mm

Wheelbase:

1970mm

Bulldozer branch height:

110mm

Tail rotation radius:

2400mm

Leg clearance from the ground:

310mm

Ground clearance of counterweight:

1070mm

Minimum ground clearance:

250mm

Hydraulic fuel tank capacity:

180L

Fuel tank capacity:

220L

Maximum excavation radius:

8360mm

Maximum excavation height:

8950mm
